محابس متنوعة

Butt welding A butt weld is the most common type of joint that is used in the fabrication of structures and piping systems. It is a circumferential weld joint where the molten metal is applied around the joint.Stainless Steel Butt Weld Fittings are made from the finest quality stainless steel designed to be dimensionally precise. The
advantages of these fittings are its high tensile strength, robust nature and rust free properties.
Stainless Steel butt-weld fittings made from welded stainless steel pipe which is manufactured from 2B or HRAP
stainless steel strip, which is formed to shape and longitudinally welded to complete the pipe -Stainless Steel Buttweld SCH10-40-80s 90 Degree Elbow

Butt welding A butt weld is the most common type of joint that is used in the fabrication of structures and piping systems. It is a circumferential weld joint where the molten metal is applied around the joint.Stainless Steel Butt Weld Fittings are made from the finest quality stainless steel designed to be dimensionally precise. The
advantages of these fittings are its high tensile strength, robust nature and rust free properties.
Stainless Steel butt-weld fittings made from welded stainless steel pipe which is manufactured from 2B or HRAP
stainless steel strip, which is formed to shape and longitudinally welded to complete the pipe -Stainless Steel Buttweld SCH10-40-80s 90 Degree Elbow

Globe valves are linear motion closing-down valves in which the closure member is moved squarely on and off the seat. Usually the closure member is referred as a disc, irrespective of its shape. The seat opening varies in direct proportion to the travel of the disc. This proportional relationship between valve opening and disc travel is ideally suited for duties involving regulation of flow rate. Globe valves are most suitable for throttling and controlling fluid flow and are generally employed in small size piping

Stainless Steel (316) Ball Valve – Full Port 1,000 PSI (WOG)Stainless Steel Ball Valve –
Full Port – 1,000 WOG (PSI) Heavy Duty For Water, Oil, And Gas With Blue Locking Handles, NPT

• S.S. 316 investment casting body
• Working Pressure of 1,000 PSI (WOG)
• Minimal pressure drop due to large full-size ports
• Suitable for full range of liquids and gas
• Temperature range: -60 to 450 Degrees F
• Low operation torque
• 100% individually tested
• Blowout-proof stem
• NPT threaded ends to ANSI B1.20.1
• Heavy duty locking handles with blue vinyl insulator

Globe valves are linear motion closing-down valves in which the closure member is moved squarely on and off the seat. Usually the closure member is referred as a disc, irrespective of its shape. The seat opening varies in direct proportion to the travel of the disc. This proportional relationship between valve opening and disc travel is ideally suited for duties involving regulation of flow rate. Globe valves are most suitable for throttling and controlling fluid flow and are generally employed in small size piping

check valve is to provide with single disc. With the force of medium, the disc will automatically open or close. When the media stops the flow, the disc will be closed under its own force. No manual intervention is involved in the whole process Check valve is mainly to prevent the media reverse flow and ensure one-way flow of media channels only. It prevents accidents while a sudden loss of power in the pipeline medium such as the power equipment like pump damages, and the medium reserve flow against power source.

• Design Std.: BSEN ISO 15761, ASME B16.34.
• Pressure Temperature Rating as per ASME B16.34, BSEN ISO 15761.
• Sturdy design for high-pressure & temperature service.
• Bolted body-cover design, Valves with welded cover also available on request.
• Bolted body-cover joints provided with spiral-wound stainless steel gasket and graphite filler for protection against leaks.
• Piston/Disc is guided in the Cover assuring accurate return to seating to achieve leak tightness.
• Spring-loaded disc on check valves suitable for non-horizontal applications too available on request.
• Minimum differential pressure of 1 bar required for operating the valve.
• Socket welded ends as per ASME B16.11.
• Screwed Female Taper ends as per ASME B1.20.1 (NPT)/BS 21 & Screwed Female Parallel ends as per ISO 228/BS 21 available on request.
• Socket-weld Class 800 Reduced Bore valves confirm to Class 3000 (or Sch.80/Sch. XS) fittings of ASME B16.11.
• Socket-weld Class 800 Full Bore valves confirm to Class 6000 (or Sch.160) fittings of ASME B16.11.
• Butt weld ends as per ASME B 16.25 available on request.
• Low-Temperature Carbon Steel & Austenitic SS forging for body and cover design qualified as per BS 6364 for Cryogenic service available on request.
• Valves can be offered to NACE MR-0175 and other special NACE requirements.
• Valves are available with IBR certification.

Globe valves are linear motion closing-down valves in which the closure member is moved squarely on and off the seat. Usually the closure member is referred as a disc, irrespective of its shape. The seat opening varies in direct proportion to the travel of the disc. This proportional relationship between valve opening and disc travel is ideally suited for duties involving regulation of flow rate. Globe valves are most suitable for throttling and controlling fluid flow and are generally employed in small size piping
